multi-head auger filling machine

Model No Production per hour
JPMA-4 7000
JPMA-6 10500
JPMA-8 14000
JPMA-10 17500
JPMA-12 21000

* The output of the machine depends on powder’s inherent characteristics, ambient atmospheric conditions, fill volume and container geometry.

* Specification subject to change without prior notice.

Application: To fill Dry syrup/Powder in containers

Inquiry
Machine Detail Accessories & Utillties Optional Features Application

Competencies

  • » Total CGMP model
  • » Frame Made from SS-structure, with height adjustment
  • » Sleek sturdy and compact design
  • » All controls from the panel
  • » Left to right and right to left options available
  • » PLC HMI-Touch screen

Features

  • » Multiple dispensing units in single hopper mechanism.
    •    [Send us inquiry to know manyfold benefits of it]
  • » No bottle no fill arrangement
  • » Requires minimum bottle change parts and very quick changeover.
  • » Very high dosing accuracy
  • » Parts can be easily declamped/clamped for quick cleaning and changeover
  • » Completely Fail safe design
  • » No bottle no fill arrangement

Accesseries

  • » Dust collector
  • » Spoon Feeder
  • » Powder loader
  • » Pre/post check weigher
  • » Pre/post inspection unit

Utilities

  • » 415V, 3-phase, 50hz electric supply
  • » Electric load:- 5HP
  • » Air:- 5 CFM @ 4 to 6 kg/cm2
  • » Vibratory mechanism for sticky or hygrospcopic powder
  • » Synchronisation with nitrogen Purging
  • » Mechanized slug breaker
  • » Integration for check-weightier /inspection units
  • » Rejection of non-accurate bottles
  • » Weighing of each dose
  • » Monoblock machine for Screw capping/ROPP capping
  • » To fill Dry syrup/Powder in containers
  • » Container diameter:- 30 to 90 mm
  • » Container height:- 30 to 150 mm
  • » Dose:-20 gm to 1000 gms
